Tial MV-S Wastegate 38mm Blue w/ All Springs (Part Number: )
Tial MV-S Wastegate 38mm Blue w/ All Springs (Part Number: )
Tial MV-S Wastegate 38mm Blue w/ All Springs (Part Number: )
Tial MV-S Wastegate 38mm Blue w/ All Springs (Part Number: )
Tial MV-S Wastegate 38mm Blue w/ All Springs (Part Number: )
Tial MV-S Wastegate 38mm Blue w/ All Springs (Part Number: )
Tial MV-S Wastegate 38mm Blue w/ All Springs (Part Number: )
Tial MV-S Wastegate 38mm Blue w/ All Springs (Part Number: )
Tial MV-S Wastegate 38mm Blue w/ All Springs (Part Number: )
Tial MV-S Wastegate 38mm Blue w/ All Springs
Universal
Read 6 Reviews | 21 Q&As
Part # MVSB
$386.10
msrp: $429.00

In stock! Ships same day
Universal part

Features & Product Details

RallySport Direct is proud to carry the Tial MV-S 38mm External Wastegate in the blue finish.

Tial MVS(38mm) Wastegates feature a High temp NiCrFe based alloy is used for valve and 347SS valve housing will offer longer product life, high-temperature silicone Nomex reinforced actuator diaphragm, 17-7 PH Stainless Steel actuator spring gives consistent pressure at high temperature, resist "relaxing" at temperature to 900°F (483°C), Nitronic 60 Stainless Steel is used for the valve seat, and valve bushing, all Stainless Steel hardware, mating weld flanges are 304L. As well as 3 lower ports and two top ports for easy install, no need to rotate the actuator top at all, plugs included for unused ports, an ultra-compact design fits in very tight spaces, the unit stands only 3.7" tall, more compact than any other external wastegate on the market today and a V-Band inlet and outlet make installation easy.

Sometimes springs come pre-installed from Tial so you will want to verify the spring settings before installation.


  BAR PSI DESCRIPTION O.D. 0.3 4.35 Green 1.125 in 0.4 5.80 Red 1.500 in 0.5 7.25 Yellow 1.125 in 0.6 8.70 Black 1.875 in 0.7 10.15 Red + Green   0.8 11.60 White + Green   0.9 13.05 Black + Green   1.0 14.50 Black + Red   1.1 15.95 Blue + Yellow   1.2 17.40 Black + Blue   1.3 18.85 Black + Red + Green   1.4 20.30 White + Blue + Green   1.5 21.75 Black + Blue + Green   1.6 23.20 White + Blue + Yellow   1.7 24.6551 Black + Blue + Yellow

Specifications

Brand: Tial
Color: Blue
Flange Size: 38mm
Flange Type: V-Band
Includes Hardware: Yes
Includes Spring: Yes, All Springs
Material: Stainless Steel / Aluminum
Pressure Rating: 0.3-1.7 bar
Type: External
Water Cooled: Yes
Mfgr. Warranty: Limited Lifetime Warranty
Condition: New Product
Return Policy:

RallySport Guarantee - 30 Days


Items that are covered under the RallySport Guarantee offer a 30 day no questions asked return policy.

RallySport Guarantee items may be returned within 30 days of the original invoice date and must include all the original parts and contents for a refund.

The RallySport Guarantee does not apply to products that have been modified, damaged, misused or abused. All returns require an RMA (Return Merchandise Authorization) Number, and freight charges are strictly non-refundable. For more information regarding our freight refund policy, please refer to our return policy page found HERE.
Standard

PEOPLE WHO VIEWED THIS ITEM ALSO VIEWED

REVIEWS & CUSTOMER MEDIA

6 Reviews
5 out of 5 Stars
5 Stars
(6)
4 Stars
(0)
3 Stars
(0)
2 Stars
(0)
1 Stars
(0)
Customer Photos and Videos
No user media. You can upload a photo or video of your install by posting a review.
Awesome! 2 years ago

This thing is LOUD! I have this coupled with the grimmspeed uppipe and it sounds amazing. Gained about 10whp 15trq after mustang dyno tune. Holds boost well and does seem to make turbo spool up a wee bit faster. Be warned again. It is loud. U probably dont want to show it off if/when there is a cop near by or even a one block radius of you. Only opens up at wot. But it does sound amazing. And very addicting. Until you pass the honeymoon stage. Then it can get annoying. I just tell people its my vtech is kicking in hard. Videos do no justice on how amazing this sounds and did I mention how loud it is? Great product and made in the USA. Awesome.

Was this review helpful?
Great mid range ewg 3 years ago
Pineappledood
Good product relatively easy install. I didn't realize how bad of shape my iwg was until I put this thing on. Now my turbo spins up like a top with no waste gate flutter. According to my tuner I'm also hitting peak boost around 500 rpm quicker. I'm only running 17psi but judging the overall quality of the product I'm sure it could handle pretty much any amount of boost you throw at it especially if you took the time to run lines to the included water cooling ports (which is totally unnecessary unless it's on a legit race car) Note: be sure to triple check when YOUR ewg came out so you can positively be using the right spring chart on tials website

Was this review helpful?
Awesome item 3 years ago
chris8889m89419
Amazing sound and great quality.

Was this review helpful?
Great Wastegate 5 years ago
Castper
This thing is awesome, works well and I have had no problems with it. Sounds amazing in my WRX.

Was this review helpful?
2 of 2 people found the following review helpful
Tial 38mm EWG 6 years ago
ThatBoxerGrowl
After installing this with the Grimmspeed uppipe and getting it dyno tuned I picked up another 40 hp and 35 lb/ft at the wheels. One of the best power adders for the money I've seen so far!

Was this review helpful?

QUESTIONS & ANSWERS

  • Q: 38 or 44  Josh1 month ago

    I have a 2014 wrx. Stock turbo, Invidia catless downpipe and dual n1. Plan on installing an electronic boost controller. Which size wastegate should I use?
    • 0 of 0 people found the following answer helpful

      A:  Hi, Josh, with a stock turbocharger in place, you would have plenty of additional flow capability with the TiAL MVS (38mm) wastegate, well past the limit of that stock turbo.

      TiAL @ Tial 1 month ago

      Was this answer helpful?
  • Q: Spring set up tial wastegate   White__sti6 months ago

    I need help on setting up the springs for my 38mm tial wastegate on my 2011 STI Do i set the springs to the sport mode boost pressure or the sport # boost pressure ? I’m currently running 16psi on sport and 20psi on sport# I’ve heard to do the higher boost pressure but I’ve also heard to do the lower one?
  • Q: Tial 38mm bov  hfrohlich56 months ago

    Will the tial 38mm bov fit on my stock 2005 wrx?
  • Q: Wastegate   RallyBlueSTI3 years ago

    I have a 2013 STI with the Invidia Catless Divorced Wastegate downpipe along with a pro tune. Will this wastegate be compatible with my downpipe? and if so, how much HP and torque will I gain?
    • 0 of 0 people found the following answer helpful

      A:  The wastegate is installed before the turbocharger either on an uppipe modified for a wastegate or on an exhaust housing of the turbine if you have a turbocharger that allows for that. The downpipe is not going to effect fitment.

      Nick S. @ RallySport Direct 3 years ago

      Was this answer helpful?
  • Q: Spring psi  100plus2vegas3 years ago

    Is it true that your overall psi is double the spring psi? I'm currently running about 18.75psi on my stock turbo on a 14 wrx ej255. Would this 38mm waste gate be a better choice than the larger 40-45mm waste gates? Thanks.
    • 0 of 0 people found the following answer helpful

      A:  The spring PSI should be the same as the boost pressure, and you can raise the boost higher than the spring rating with a boost controller. Wastegate sizing depends on how much exhaust needs to be vented and if you are running 17+ PSI on the stock turbo, then this EWG would work well because you don't need to vent much exhaust.

      Zach G. @ RallySport Direct 3 years ago

      Was this answer helpful?

This Part Fits

Universal Product
This item is non application specific.
Please verify compatibility before purchase. May require some modification for proper installation.
