Tial MV-S Wastegate 38mm Silver w/ All Springs
Universal
Write a Review | 1 Q&As
Part # MVS
$305.10
msrp: $339.00

Only 2 left!
Universal part

Features & Product Details

Tial MVS(38mm) Wastegates feature a High temp NiCrFe based alloy is used for valve and 347SS valve housing will offer longer product life, high temperature silicone Nomex reinforced actuator diaphragm, 17-7 PH Stainless Steel actuator spring gives consistent pressure at high temperature, resist "relaxing" at temperature to 900F (483C), Nitronic 60 Stainless Steel is used for the valve seat, and valve bushing, all Stainless Steel hardware, mating weld flanges are 304L. As well as 3 lower ports and two top ports for easy install, no need to rotate the actuator top at all, plugs included for unused ports, an ultra compact design fits in very tight spaces, the unit stands only 3.7" tall, more compact than any other external wastegate on the market today and a V-Band inlet and outlet make installation easy.

Sometimes springs come pre-installed from Tial so you will want to verify the spring settings before installation.

BAR PSI DESCRIPTION O.D. 0.3 4.35 Green 1.125 in 0.4 5.80 Red 1.500 in 0.5 7.25 Yellow 1.125 in 0.6 8.70 Black 1.875 in 0.7 10.15 Red + Green 0.8 11.60 White + Green 0.9 13.05 Black + Green 1.0 14.50 Black + Red 1.1 15.95 Blue + Yellow 1.2 17.40 Black + Blue 1.3 18.85 Black + Red + Green 1.4 20.30 White + Blue + Green 1.5 21.75 Black + Blue + Green 1.6 23.20 White + Blue + Yellow 1.7 24.6551 Black + Blue + Yellow

Specifications

Brand: Tial
Color: Silver
Flange Size: 38mm
Flange Type: V-Band
Includes Hardware: Yes
Includes Spring: Yes, All Springs
Material: Stainless Steel / Aluminum
Pressure Rating: 0.3-1.7 bar
Type: External
Water Cooled: Yes
Mfgr. Warranty: Limited Lifetime Warranty
Condition: New Product
Return Policy:

RallySport Guarantee - 30 Days


Items that are covered under the RallySport Guarantee offer a 30 day no questions asked return policy.

RallySport Guarantee items may be returned within 30 days of the original invoice date and must include all the original parts and contents for a refund.

The RallySport Guarantee does not apply to products that have been modified, damaged, misused or abused. All returns require an RMA (Return Merchandise Authorization) Number, and freight charges are strictly non-refundable. For more information regarding our freight refund policy, please refer to our return policy page found HERE.
Standard

PEOPLE WHO VIEWED THIS ITEM ALSO VIEWED

REVIEWS & CUSTOMER MEDIA

Be the first to write a review

QUESTIONS & ANSWERS

  • Q: Waste gate size  Humpy3 years ago

    What's the difference between the 38mm and 44mm wastegate
    • 0 of 0 people found the following answer helpful

      A:  Wastegate size determines how much air can be bypassed and for best response you will want to match up the correct size to your setup.

      Nick S. @ RallySport Direct 3 years ago

      Was this answer helpful?

This Part Fits

Universal Product
This item is non application specific.
Please verify compatibility before purchase. May require some modification for proper installation.
