Mishimoto Performance Aluminum Radiator Manual Transmission - Subaru Forester XT 2004-2008

MODEL # MIS MMRAD-FXT-04
Manufacturer Part # MMRAD-FXT-04

$330.00

MSRP: $440.00

24
hours
Only 2 left!
Qualifies for free shipping!


Buy as a package deal and save:
Aluminum Radiator Kit ( Part Number:RSD 04-08FXTRADUP)
Aluminum Radiator Kit - Subaru Forester XT 2004-2008
As low as $401.58
View Product

Description

RallySport Direct carries a large selection of the Mishimoto X-Line Performance Aluminum Radiator to not only improve the cooling efficiency of your vehicle but to also make for an excellent upgrade over your factory unit.

Here are the key features:

  • Full aluminum construction provides increased heat and pressure tolerance, improved heat dissipation, increased durability and improved cooling efficiency
  • 3-row core
  • Manufactured with TIG-welded end tanks for improved strength and extended service
  • 100% brazed aluminum core for maximum reliability
  • Increased coolant capacity directly results in improved cooling efficiency
  • Included 1.3 BAR radiator cap raises the boiling point of engine coolant to provide a safer and more efficient system
  • Designed to original equipment specifications
  • Designed for manual transmission models

Please note: The radiator cap provided with this particular radiator should replace the stock cap that is located n the expansion tank. Your factory issued/stock radiator cap should be the one used on the Mishimoto Radiator. The Mishimoto radiator cap is a two-way valve, and when compared to the stock single valve, there is a difference in construction, and cannot be used on the radiator. If you try to use the provided Mishimoto cap on the radiator, then you risk overheating.

Upper radiator hose may require trimming for proper clearance.

SHARE THIS
| | | | |

RallySport Guarantee - 30 Days


Items that are covered under the RallySport Guarantee offer a 30 day no questions asked return policy.

RallySport Guarantee items may be returned within 30 days of the original invoice date and must include all the original parts and contents for a refund.

The RallySport Guarantee does not apply to products that have been modified, damaged, misused or abused. All returns require an RMA (Return Merchandise Authorization) Number, and freight charges are strictly non-refundable. For more information regarding our freight refund policy, please refer to our return policy page found HERE.

Specifications


Brand: Mishimoto
Core Depth: 1.65 in
Core End Tank Material: Aluminum
Core Height: 14.10 in
Core Width: 27.00 in
Includes Radiator Cap: Yes

Mfgr. Warranty: Limited Lifetime
Condition: New Product
Return Policy:

RallySport Guarantee - 30 Days


Items that are covered under the RallySport Guarantee offer a 30 day no questions asked return policy.

RallySport Guarantee items may be returned within 30 days of the original invoice date and must include all the original parts and contents for a refund.

The RallySport Guarantee does not apply to products that have been modified, damaged, misused or abused. All returns require an RMA (Return Merchandise Authorization) Number, and freight charges are strictly non-refundable. For more information regarding our freight refund policy, please refer to our return policy page found HERE.
RallySport Guarantee

PEOPLE WHO VIEWED THIS ITEM ALSO VIEWED

5

5 STAR
100%
4 STAR
3 STAR
2 STAR
1 STAR
Verified Purchase

Mishimoto Aluminum Radiator
Sovermeyer79 1 year ago
The radiator fits perfectly with no modifications. Although it is a bit wider than stock. After you install the fans back on there is not much room between the radiator and the belts. You can adjust the tension on the power steering belt without any issues. But the space between the AC belt and radiator is super tight. Make sure you have it adjusted properly before finishing the install. The only modification was on the radiator itself. The overflow nipple is screwed in by the installer. Since it is aluminum the threads are super delicate. Mine stripped out, so I had to use a tap and die set along with some JB Weld to make it a permanent fixture. Other than that it is a great looking and performing radiator. Just as a hint: It gets super hot on top. Be careful when working around it after the. Whichever had been ran.
Comment
Verified Purchase

2004 Forester XT Radiator
dw89086 2 years ago
The Mishimoto radiator has a much thicker core than stock, but this was a direct fit and I had no issues installing it. It really helped to have one person under the car to guide the studs into their mounting points, but the install was about as straight forward as could be. I bought the Mishimoto silicone radiator hoses along with this since I was already pulling it apart... OEM hoses appeared fine and probably could have been reused but I just replaced them, so I can't comment on fitment with this radiator. Note that with this radiator model on a 2004 Forester XT, you can either use the bolt provided to close off the hole coming out of the side of the main filler neck (be sure to check that it's threads aren't extending through the thickness of the aluminum as it will damage the radiator cap if you screw that on with the threads sticking into the neck (This problem may be resolved now, I didn't even check since I was planning to use the other fitting anyway). Some people have use a dremel or something similar to trim the length of threads as needed, if it's too long. Alternatively, you can use the extended fitting provided which had the perfect threaded length which didn't extend beyond the thickness of the aluminum. You can then buy a brass t-fitting to connect this piece to the hose running between the overflow bottle and the main coolant reservoir. This is my plan but I was still waiting to receive the t-fitting but needed to get the new radiator in as mine had been leaking for a couple weeks, so for now I just blocked that piece off with a bolt plugging the end of the hose and some clamps... works just fine and theoretically I could leave it like this with no issue.
Comment

Holy huge!
kentrik 2 years ago
About two months ago, I installed this along with the Mishimoto radiator hoses on my 07 Forester XT (4EAT - I had to add an external trans oil cooler, but it was easy), and it is BIG. The dimensions of the caps are the same, but the core is MUCH thicker - expect to not have a lot of wiggle room to replace your belts anymore. This thing is monstrous, and took much more fluid than the stock one, but I can imagine that it cools much better. Unfortunately, I didn't add a temp gauge, so it's hard to tell, but I have yet to have it overheat, even with running it a bit hard. A note - I did trim the upper radiator hose about 3/8" on either side because of the space taken up by the new fitment, but the Mishimoto hoses are awesome and a great add-on to this sweet radiator.

Comment

forester xt radiator
jfmartel1749086 3 years ago
perfect fitment,great low price ,great craftmanship. the inlet and outlet on the rad are a tad bigger in diameter so your hose will be a tight fit ,a drop of oil will help. good time to change youre old hoses too and dont forget the thermosthat
Comment
Verified Purchase

Subaru Forester XT Radiator
baker.steven21521269 4 years ago
This is an excellent radiator, wish I had replaced it sooner. It was easy and dropped right in, just like in the video tutorial. I did modify the little plug for the overflow which is not used on my model. That was not a big deal.. I also installed a set of the Mishimoto Silicone radiator hoses... they fit perfect.. a little trimming on each one for that perfect fit. Great products..
Comment

  • Q: What is the actual optimal temperature for the Subaru  rsokol8612443 4 years ago

    Answer

    I installed a gauge and it seems to stay 190-200f after it warms up What is it meant to be?


    • A: Hello, The temperature you are quoting seems normal, however, this would depend greatly on the thermostat you are running.


      Mishimoto 4 years ago
    • A: Yes, that is the stock temperature range.


      guest56ad69792a8d256e198b66b5 4 years ago
  • Q: Temp  rsokol8612443 4 years ago

    Answer

    Does this 2 core radiator actually make your car run cooler? What is the benefit of switching from stock


    • A: Yes, the 2 row Mishimoto radiator will be more efficient that the OEM unit you have now. Aluminum will dissipate heat much faster than plastic, which is known to retain heat. Also, after numerous heat cycles, the plastic starts to become brittle and will crack. The aluminum construction of the Mishimoto radiator will not crack over time.


      Mishimoto 4 years ago
    • A: Your car will run at similar temps it just prevent any over heating issues when the car is under a lot of stress or heavy load. Another benefit is that it is a solid aluminium piece so you don't have to worry about any of the plastic housing on your OEM radiator cracking or breaking.


      guest57853c642a8d25b5018c44a7 4 years ago
  • Q: automatic transmission  acostaj3291125 4 years ago

    Answer

    does mishimoto make there radiator for automatic transmission


    • A: At this time this is the only radiator we offer for the forester, Mishimoto doesn't list an automatic version


      Kyle A. 4 years ago
    • A: I have this radiator on my 04 FXT 4EAT. Mishimoto sells a generic cooler you add on for the automatic transmissions.


      blairellis64232955 3 years ago
    • A: I have this radiator on my 04 FXT 4EAT. Mishimoto sells a generic cooler you add on for the automatic transmissions.


      blairellis64232955 3 years ago
